Hardness Tester, Sand Mould Surface Hardness Tester HT-6510S-B for Fine and Coarse Sand/core in Manual Or Mechanical Low and Medium Pressure for Steel Iron Bronze Copper

The Sand Mould Surface Hardness Tester is used to measure the surface hardness of the sand mould/core of the wet and provide technical parameters for the formulation of the ing processFeatures* It meets standards of DIN 53505, ISO 868, ISO 7619, ASTMD 2240, JISK7215.* The surface hardness of sand is divided into three types: A, B and C, The common model is type B, among them:Type A: Suitable for the surface hardness test of fine sand /core in manual or mechanical low and medium pressure ing.Type B: Suitable for the surface hardness test of fine and coarse sand /core in manual or mechanical low and medium pressure ing.Type C: Suitable for the surface hardness test of sand in high pressure ing.* The unit of type B hardness tester for sand surface is (g/mm2), but it is customary to use hardness H(A/B/C) instead of unit. Because their values are related and consistent, the corresponding hardness value is also large when the unit value is large (g/mm2).sand mould surface hardness tester, Hardness Testers, Physical Measuring Instruments, Measurement & Analysis Instruments

• * With average calculate function.
• * Peak value deposit function.
• * Under-voltage alarm function.
• * Use USB data output to connect with PC.
• * Provide data output choice.
